Highest Configuration 6 Heads SMT pick and place machine Robot

3 Pieces Auto PCB Conveyor, Double Y axis, 6 Heads 50 Feeders, Servo Motor, Automatic Nozzle Change, Higher accuracy CPK test passed, 0201 support, IPC9850: 13400CPH. CPK≥1.0 (X Y)

Medium SMT Production line, For PCBA SMT assembly line

This is an updated model CHM-751 from Charmhigh with economic price, it has high configuration and higher preicision, if you want a high precision machine with a economic price, this one is your best choice! This model has 3 pieces auto PCB conveyor, it can connect with SMT conveyor desk and reflow oven, delivery PCB into reflow oven.

Introduction:

1. Model number: CHM-751
2. Brand: Charmhigh
3. Main configuration: High precision CPK test passed + 0201 support + Auto PCB conveyor + CPK test passed + Auto nozzle change + Max speed 18400 CPH + 6 heads 50 feeders + double Y axis + Ball screw with + Servor motor + 9 cameras + Yamaha feeders + intelligent software
4. Max PCB area: 400*350mm
5. Component: 0201/0402/0603～5050/SOT/SOP/QFP/QFN/BGA, etc. (resistor/capacitor/diode/triode/LED/IC, etc.)
6. Dimension: 1280mm(L)×1190mm(W)×1470mm(H)
7. Lead time: 5-7 working days
8. Delivery: by air, by sea, or pick up from our factory, or ship to shipping agent
9. Payment method: wire transfer (T/T); credit card; W/U
10. Packing: plywood box
11. HS code: 8479.89.62.00 (Pick and place machine)

CHM-751 catalog download: CHM-751 - Catalog.pdf

Highlight:

1. Thermal Compensation

2. Support CPK test, 0201 perfect mounting

3. Built-in Vacuum Pump

4. Automatic nozzle change (19 sets nozzle library)

5. PCB Support Device

6. 6 head + 50 Yamaha feeder stacks + 9 cameras

7. Double Y axis with grinding screw, y axis with servo motors

For more machine features, please consult our account manager

Service & Warranty:

The complete machine has a warranty period of 1 year from the time of purchase and lifetime service.

We always provide spare parts of machine, factory reliable direct supply.

We provide online Q/A and troubleshooting support and technical advice service.

Provide one to one after-sale service. Each machine 100% tested well before ship out.

Tech support & Contact:

Kimi Liu

Charmhigh Technology Limited

Mob/ WhatsApp: 0086 135 106 75756

Skype: kimiliu89

E-mail: kimi@charmhigh-tech.com

Welcome to follow us in YouTube: https://www.youtube.com/c/KimiLiuCharmhigh/videos

If you want to see more information and videos, please contact us by E-mail.

We will response you at the first time.

CHARMHIGH TECHNOLOGY LIMITED is a professional SMT pick and place machine and SMT production line equipment maker which founded in 2009. The company is located in the Hunan province Changsha High-tech Development Zone, covering a total area of 3600 square meters. As a professional modern science and technology enterprise capable of both R&D, production and marketing, Charmhigh has been leading the way in SMT technology for more than ten years.
We start up business from CNC router  since 2009, our engineers had plenty experiences on machinery and motion control system, so we added SMT technology into our business since 2012.

Now our 2 heads and 4 heads desktop SMT pick and place machines are for the majority of small and medium SMT manufacturing research & developments organization, LED Lights, Driver Cards or any Similar Types of Manufacturing Facilities. Our 6 heads, 8 heads and 12 heads vertical standard high speed SMT machine is for big volume production factories. We provide one-stop SMT solution to different customers.

By now, the products of our company have been sold to many countries, such as the United States, Canada, United Kingdom, Italy, Germany, Spain, Poland, Australia, Russia etc.

We are very keen to stay up to study with the latest SMT technology, we have confidence to create more quality products. We take after-sales service as the most important thing, please don't hesitate to contact with us if you have any questions or new ideas.

Charmhigh new building
