SMT Automatic PCB Loader For SMT Assembly line and Electronic Products Machinery

1. Simple structure in linear type, easy in installation and maintation.
2. Adopting advanced world famous brand components in pneumatic parts , electric parts and operation parts.
3. High pressure double crank to control the die opening and closing.
4. Running in a high automatization and intellectualization,no pollution
5. Apply a linker to connect with the air conveyor ,which can directly inline with filling machine .

Description:

Features:

1. Intelligent touch screen + Siemens PLC control system
2. Abnormal, with automatic fault diagnosis, sound, tricolor light and other alarm functions
3. PCB positioning: Taiwan Zhongda motor + photoelectric sensor
4. PCB transportation direction: right → left or left → right
5. Applicable PCB size: 50 * 50-320 * 250mm
6. Transmission height: 900 ± 20 mm
7. Power demand: voltage AC 220V / 50 / 60 Hz
8. Air source compressor requirement: 0.4-0.6mpa
9. PCB rack size fill inside loader: 355 * 320 * 563mm
10. Automatic replacement of PCB rack
11. Brake system: Taiwan Zhongda motor brake system is adopted
12. Transmission system: Taiwan TBI ball screw + ￠30mm bearing steel bar
13. Overall dimension: 1200mm * 800mm * 1350mm
