Automatic PCB Conveyor 0.6m for SMT Production Line Speed Adjustable 0.5/0.6m/1.0m/1.2m/1.5m

A PCB conveyor, also known as a PCB handling conveyor or PCB link conveyor, is an essential piece of equipment used in the electronics manufacturing industry. It is designed to transport printed circuit boards (PCBs) between multiple machines or workstations during the assembly process.

Parameters

Using a PCB conveyor is relatively simple and involves the following steps:

1. Installation: The conveyor system needs to be properly installed in the manufacturing line, ensuring that it is securely fixed and aligned with other machines or workstations.

2. PCB Loading: PCBs are carefully placed on the conveyor, either manually or using an automatic loading mechanism. It is crucial to ensure that the PCBs are neatly positioned and aligned with the transport direction to avoid any jams or misalignments.

3. Speed Adjustment: Depending on the specific manufacturing process and the desired speed of operation, the conveyor's speed can be adjusted using the control panel or interface provided. It is important to set the speed correctly to maintain the required production rate while preventing any damage to the PCBs.

4. PCB Transfer: The conveyor moves the PCBs along the assembly line, ensuring a smooth transfer between machines or workstations. The rollers or belts gently facilitate the movement, preventing any slippage or unnecessary stress on the PCBs.

5. Unloading: Once the PCBs reach the desired destination, they are either manually unloaded or transferred to the next process through an automated system. Care should be taken during unloading to avoid any mishandling or damage to the PCBs.

6. Maintenance: Regular maintenance of the PCB conveyor is crucial to ensure its optimal performance and longevity. This includes cleaning the rollers or belts, checking for any signs of wear or damage, and lubricating the moving parts as recommended by the manufacturer.

In conclusion, a PCB conveyor is an indispensable tool for efficient and reliable transportation of PCBs during the assembly process. Its ease of use, time-saving capabilities, and ability to minimize damages make it an essential component in modern electronics manufacturing.

Conveyor with lamp:

Charmhigh, famous brand in China, specializing in SMT industry for over 13 years, providing strong support.

Service & Warranty:
The complete machine has a warranty period of 1 year from the time of purchase and lifetime service.
We always provide spare parts of machine, factory direct supply with guarantee.
We provide online Q/A and troubleshooting support and technical advice service.
We provide one to one after-sale service. Each machine 100% tested well before ship out.
Tech support:
Kimi's Mob/ WhatsApp: 0086 135 106 75756
Skype: kimiliu89

E-mail: kimi@charmhigh-tech.com
Welcome to follow us on YouTube: https://www.youtube.com/c/KimiLiuCharmhigh/videos
If you want to know more information, please contact us by E-mail.
We will response you at the first time.

CHARMHIGH TECHNOLOGY LIMITED is a professional SMT pick and place machine and SMT production line equipment maker which founded in 2009. The company is located in the Hunan province Changsha High-tech Development Zone, covering a total area of 3600 square meters. As a professional modern science and technology enterprise capable of both R&D, production and marketing, Charmhigh has been leading the way in SMT technology for more than ten years.
We start up business from CNC router  since 2009, our engineers had plenty experiences on machinery and motion control system, so we added SMT technology into our business since 2012.

Now our 2 heads and 4 heads desktop SMT pick and place machines are for the majority of small and medium SMT manufacturing research & developments organization, LED Lights, Driver Cards or any Similar Types of Manufacturing Facilities. Our 6 heads, 8 heads and 12 heads vertical standard high speed SMT machine is for big volume production factories. We provide one-stop SMT solution to different customers.

By now, the products of our company have been sold to many countries, such as the United States, Canada, United Kingdom, Italy, Germany, Spain, Poland, Australia, Russia etc.

We are very keen to stay up to study with the latest SMT technology, we have confidence to create more quality products. We take after-sales service as the most important thing, please don't hesitate to contact with us if you have any questions or new ideas.
